H1926-HS
High Speed HDMI® Cable with Ethernet

The H1926-HS is the first aerospace-grade cable to achieve HDMI certification, meeting HDMI specifications. Engineered to transmit uncompressed video, it transports 4K resolution up to distances of 5m (16.4 ft).

With a smaller diameter and reduced weight, it offers easy installation and routing in tight spaces of aircraft and vehicles. Ideal for military surveillance and civil aircraft entertainment systems, it incorporates HDMI® technology for unmatched compatibility and reliability.



The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.

H1926-HS Product Bulletin

H1926-HS Burn Test Data

Cable Construction

DATA PAIRS:
Conductor: Silver-Plated Copper Alloy
Dielectric: PTFE
Binder: PTFE Tape (each pair)
Drain Wire: Silver-Plated Copper Alloy (each pair)
Individual Shield #1: Aluminum/Polyimide (each pair)
Binder: PTFE Tape

SINGLE WIRES:
Conductor: Silver-plated copper Alloy
Dielectric: PTFE
Overall Shield #1:Aluminum/Polyimide
Overall Shield #2: Round Silver-Plated Copper
Jacket: PTFE Tape, White (Laser Markable)

../CableConstructionImageAltText

Color Codes

  • Pair #1: White, Blue
  • Pair #2: White, Red
  • Pair #3: White, Green
  • Pair #4: White, Brown

Physical Data

  • Conductor:26 AWG Stranded SPCA
  • Shield Coverage:100% Foil / 85% Braid
  • Temperature Range: -55/+200°C
  • Outer Diameter: in (mm)0.28 (7.24)
  • Minimum Bend Radius: in (mm)1.30 (33.02)
  • Weight: lbs/100 ft (kg/100 m)6.00 (8.93)

Electrical Data

  • Impedance: ohms100
  • Dielectric Voltage Rating: (kV, RMS)1.50
  • DC Resistance: ohms/1000 ft (m)44.80 (147.00)
  • Max Distance:* ft (m)16 (5)

Attenuation

Frequency     MAX dB/ft (5m)

@825 MHz       0.30 (5.0)
@2475 MHz     0.73 (12.0)
@4125 MHz     1.22 (20.0)
@5100 MhZ      1.52 (25.0)

Spec Sheet Includes:

  • Assembly Loss at
  • Product Bulletin
  • Burn Test Data

Get Spec Sheet
