Single Pair Ethernet

1000BASE-T1, Type B Standard

Single Pair Ethernet

Main Content

Single Pair Ethernet (SPE) represents the next evolution in connectivity solutions for aerospace applications. At PIC Wire & Cable, our PICMates E1G4222 cables deliver exceptional performance as a lightweight solution in demanding environments. Aligned with aerospace goals for weight reduction, cost savings, and enhanced sustainability, SPE is setting new standards in connectivity.

Key Features and Benefits

  • Compact & Lightweight Design: Reduces weight and space requirements by up to 50% compared to four-pair Ethernet cables, enhancing fuel efficiency and reducing emissions.
  • Robust Performance: Shielded 22 AWG twisted pairs deliver reliable signal integrity over extended run lengths, ensuring compliance with IEEE 802.3-2022 1000BASE-T1 Type B standards.
  • Enhanced Durability: Built with stranded conductors and dual shielding to resist vibration, flexing, and electromagnetic interference.
  • Dual Shields and Drain Wire: Protects against a broad range of frequencies, offering exceptional performance in complex cabin and avionics environments.
  • Future-Ready: Supports next-generation aircraft networks with smarter, more efficient cabin systems.

Applications in Aerospace
The PICMates E1G4222 cable is tailored for a wide range of mission-critical aerospace systems, including:

  • Avionics networks
  • Cabin management systems
  • Digital video and sensor systems
  • In-flight entertainment systems
  • Ethernet backbone and databuses

The E1G4222 cable revolutionizes aerospace networking by replacing traditional four-pair Ethernet cables with an advanced single-pair design. This breakthrough enables gigabit-speed data transmission with reduced space and weight requirements, all while ensuring superior signal integrity and durability. Engineered to meet IEEE 802.3-2022 1000BASE-T1 Type B standards, the E1G4222 supports run lengths up to 40.6 meters and thrives in the harshest aerospace environments.Elevate your connectivity with PICMates SPE cables.

Discover reliability and high performance of the E1G4222 Single Pair Ethernet Cable.

Designed for

Corporate

Single Pair Ethernet is a lightweight, cost-effective cable that ensures smooth and secure operation of an aircraft's network and internal/cabin systems. Elevate your connectivity with a cable that rivals its predecessors, delivering uncompromising performance.

Commercial

Designed for providing top of the line in-flight entertainment and superior cabin management connectivity, Single Pair Ethernet is your solution to keeping digital and physical operation running smoothly. Expereince reliability and high performace with a fraction of the weight.
